Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: HD-650D
Download Sealing machine automaticSpecifications:
Control Microprocessor
Sealing process: automatic / reproducible
CE sign, GS sign : x
Calibration certificate : x
Conformity ISO 11607-2:2006: x
Conformity DIN 58953-7:2010: x
Conformity DGSV guideline: x
Sealing system: ribbed seal
Sealing distance from edge 0 – 35 mm (0 –1.4 in) (variable): x
Distance to medical product > 30 mm (1.2 in): x
Sealing speed (dwell) : 10 m/min (33 ft/min)
Sealing temperature max.: max. 220°C (max. 428°F)
Switch-off tolerance : ± 5°C (± 9°F)
Process parameters monitored: Sealing temperature
Machine stop in case the monitored parametersexceed predetermined limits: x
Seal seam width : 12 mm (0.5 in)
Mains connection/frequency : 115/230 V, 50/60 Hz
Power1 : 390 W
Energy-saving function, stand-by (adjustable) hd 650 DE (Stand-by)
Dimensions w x d x h (incl. infeed section) :560 x 260 x 160 mm , (22 x 10.2 x 6.3 in)
Weight: 14 kg (30.9 lb)
Casing cover: powder-coated
Sealable paper pouches: x2 Sealable
pouches and reels : x2
Control Microprocessor
Sealing process: automatic / reproducible
CE sign, GS sign : x
Calibration certificate : x
Conformity ISO 11607-2:2006: x
Conformity DIN 58953-7:2010: x
Conformity DG ... read more
Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: HD 260
Download Sealing Machine manualSpecifications:
Impulse heat sealer for the sealing of pouches and reels in medical and dental practices as well as in tattoo and piercing studios.
> No power consumption when not in use
> Adjustable sealing time
> No heating-up time, immediately ready for use
> Suitable for hot air film
> hd 470 MS: extra wide device for sealing seams up to 450 mm (17.7 in)
o Sealing System : Impulse
o Control Hd 260 : electronic
o Sealing temp Variable : ( impulse)
o Sealing time : Approx. 3-8 sec (variable)
o Power (max) : 850 W ( during sealing process)
o Seal seam width: 8 mm (0.3 inch)
o Film width Hd 260 : max. 250 mm (9.8 in)
o Seal seam length Hd 260: max. 250 mm (9.8 in)
o Mains connection / freq: 115 / 230 V , 50 / 60 HZ
o Dimensions W×D×H: 400×310×220 mm - 15.7×12.2×8.7in
o Weight : 8 Kg (17.3 Ib)
Impulse heat sealer for the sealing of pouches and reels in medical and dental practices as well as in tattoo and piercing studios.
> No power consumption when not in use
> Adjustable sealing time
... read more
Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: HM-780 DC
Download Sealing Machine WITH INTEGRATED PRINTERSpecifications:
THE INTELLIGENT GENERATION EASY ROTARY SEALERS WITH INTEGRATED PRINTER
THE HM 780 DC AND HM 780 DC-V (V = VALIDATABLE) ROTARY SEALERS WITH INTEGRATED PRINTER ARE THE ANSWER TO THE NEW REQUIREMENTS IN HOSPITALS AND PRACTICES. THEY OFFER FULL FUNCTIONALITY WITH REGARD TO SEALING SPEED, DOCUMENTATION OF RELEVANT DATA AND INTEGRATION INTO AN EXISTING INFRASTRUCTURE IN THE SMALLEST SPACE. THE HIGH QUALITY AND ROBUST MATERIALS AND OBSERVANCE OF THE HIGHEST SAFETY GUIDELINES MAKE THE GENERATION EASY EQUIPMENT THE PERFECT COMPANION FOR DAILY HYGIENE IN HEALTH CARE FACILITIES. THE NEW HM 780 DC-V IS FULLY VALIDATABLE.
HD 780 DC
Features:-
• Validatable process in accordance with ISO 11607-2
• hawo IntelligentScan for safe and easy device operation via barcode scanner
• Integrated printer with FontMatic
• SealCom ht 780 SC communication module (optional)
• Interfaces for external tracking systems (e.g. ht 180 PT-USB) and for the most batch documentation systems
• Energy-saving thanks to permanently heated sealing system and automatic stand-by function to shut off the motor when not in use (GreenTek)
INTEGRATED PRINTER
• Any normatively required information can be printed directly on the packaging during the sealing process (pictograms as per EN 980)
• Identification of manufacturer or personel number
• Product information
• Packaging time and date, expiry date
• Batch data, lot number or serial number
• Piece counter
• Designation “sterile” and Sterilization type (e.g. steam, plasma)
• Amount
• Arbitrary texts
THE INTELLIGENT GENERATION EASY ROTARY SEALERS WITH INTEGRATED PRINTER
THE HM 780 DC AND HM 780 DC-V (V = VALIDATABLE) ROTARY SEALERS WITH INTEGRATED PRINTER ARE THE ANSWER TO THE NEW REQUIREMENTS IN ... read more
Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: HM 800 DC
Download Sealing Machine with Printer HM 800 DCSpecifications:
• Rotary sealer with microprocessor-controlled printing unit
Rotary sealer with microprocessor-controlled printing unit corresponding to DIN 58953-7
These days, the sterilization of medical instruments is a must in hospitals, laboratories and the medical industry.
As such, proper handling of medical instruments begins even before sterilization by choosing the right packaging material and ensuring that the sterile package is perfectly sealed. This is the only way of guaranteeing instrument preparation that offers maximum hygiene
and safety .
The hm 800 DC is the ideal sealer for medical packaging in hospitals, laboratories and the medical industry. It satisfies the highest quality and safety standards.
Microprocessor-controlled printing unit Single-line printing above the sealed seam during the sealing process:
• Automatically updated sterilization and use-by date
• Batch and personnel number
• Symbols as per EN 980
• Text memory
• Variable font width
• Ribbon replacement from the front
• Internal printer can be switched off
• Programmable piece counter
• Elapsed hour meter
Functions
• Menu-driven device operation via digital LCD display
• Programmable in several languages: standard texts in German, English, French, Italian and Spanish
• Elapsed hour meter
• Clock and calendar function
• Batch counter can be reset
• Data storage and date updates even when device is switched off
• Motor start cut-out in the event of 5°C (41°F) deviation from the preset temperature value
Technical data
Printing unit 1-line
Printing start margin variable in mm (in.)
Sealing speed 10 m/min (32.8 ft./min)
Sealing margin 5 – 30 mm (0.2 – 1.2 in.)
infinitely variable Sealing seam 12 mm (0.5 in.)
(hawoflex sealing system)
Safety distance sealing seam to packed goods > 30 mm (> 1.2 in.)
Temperature control Microprocessor
Sealing temperature 80 – 220°C
(176 – 428 °F)
Temperature tolerance < ± 2 %
Output 500 Watt
Power supply 230 V / 50 Hz
115 V / 60 Hz
Dimensions (w x d x h) 620 x 260 x 250 mm
(24.4 x 10.2 x 9.8 in.)
Weight 23 kg (51 lb.)
• Rotary sealer with microprocessor-controlled printing unit
Rotary sealer with microprocessor-controlled printing unit corresponding to DIN 58953-7
These days, the sterilization of medical instr ... read more
Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: hm 3010 DC-V
Download Automated Rotary Heat Sealers hm 3010 DC-VSpecifications:
hm 3010/3020 DC-V rotary heat sealers feature a large 5.6” touchscreen that simplifies menu navigation and data input. Automatically seal pouches and reels, in MDRDs and sterile packaging facilities, and record critical sealing parameters for validation purposes.
The device can print all normatively requested information directly on the packaging during the sealing process (batch data, lot number, packaging date/time, product information).
Microprocessor-controlled rotary sealer with touch screenfor sterile goods packaging
hm 3010/3020 DC-V rotary heat sealers feature a large 5.6” touchscreen that simplifies menu navigation and data input. Automatically seal pouches and reels, in MDRDs and sterile packaging facilities ... read more
Company Name: HAWO
Origin: Jermany
Trade Mark: HAWO
Model: hm 631 S
Download Film roll dispenser for sterile packaging hm 631 SSpecifications:
Film roll dispenser with cutting
device for sterile packaging
The film dispenser for sterile packaging
rolls is a useful addition to the hawomed
and hawodent film sealing units. The integrated
cutting device and the possibility
of fitting several tubular and pouch film
rolls to the film dispenser make the hm RS
an indispensable part of your packaging
and sealing station.
Accessories
hawomed film dispenser hm 632 R
Technical data
Finish Stainless steel
hm RS wx h xd 873 x 430 x 420 mm
(34.3 x 16.9 x 16.5 in.)
hm 631 S wx h xd 873 x 125 x 420 mm
(34.3 x 4.9 x 16.5 in.)
hm 632 R wx h xd 858 x 425 x 200 mm
(33.7 x 16.7 x 7.9 in.)
Roll diameter max. 300mm(11.8 in.)
Cutting length approx.750mm(29.5 in.)
hm 621 S wxhxd 458 x 125 x 344 mm
(18.0 x 4.9 x 13.5 in.)
Roll diameter max. 200 mm (7.9 in.)
Cutting length max. 400 mm (15.8 in.)
Film roll dispenser with cutting
device for sterile packaging
The film dispenser for sterile packaging
rolls is a useful addition to the hawomed
and hawodent film sealing units. The integrated
cu ... read more
